The sample grabber head is installed on other sample transfer devices, such as the magnetically coupled sample transfer rod (MTA), to transfer the sample to the specified location. It is easy to operate, and the sample holder can be locked or loosened by pushing and rotating the grabber head 90°. At the same time, it has a compact structure and can pass through very small pipes.
| ● Using ultra-high vacuum compatible materials | ● Matching flag sample holder | ● Model:TH100 |
| ● Compact structure | ● Easy to operate | ● The tail is connected with a coupling with a diameter of 5-5 |
| ● Rotate 90° to complete the locking and loosening of the sample holder |
| Product name | Sample grabbing head TH | |||
| Model | TH100 | TH110 | TH120 | |
| Material | Using ultra-high vacuum compatible materials | |||
Operation Method | Grab | Rotate 90° clockwise | ||
| Release | Rotate 90° counterclockwise | |||
| Compatible sample transfer device | Magnetic coupling sample transfer rod, ultra-high vacuum manipulator | |||
| Order code | 3048200001 | 3048200013 | 3024060002 | |
