The cooling rod is a continuous flow temperature-variable plug-in that can provide 4K-400K temperature. The entire cooling rod is compatible with ultra-high vacuum environments and can be integrated with various sample stages.
● Rapid cooling: Room temperature drops to 10K in less than 15 minutes; | ● Extreme low temperature: <3K; | ● Compatible with ultra-high vacuum; |
● Unrestricted installation direction; | ● Length can be customized according to customer requirements |
Specification Model | Mounting Flange | Number of CF16 Flange Ports |
OCS35 | DN40CF | 3 |
OCS63 | DN63CF | 4 |
OCS100 | DN100CF | 5 |
KOCS40 | KF40 | - |
KOCS50 | KF50 | - |
